Description

HR-25 laboratory homogeneous emulsifier is a mechanical equipment specially designed for sample homogeneous emulsification. It can be equipped with a variety of working heads of different specifications to quickly realize sample dispersion, homogenization, emulsification, suspension, stirring, etc. At present, it has been widely used in biological animal and plant tissue cells, medicine, cosmetics, food, medicine, chemical industry and many other fields.

Features

A variety of working heads of different specifications to meet the processing capacity of 2~10L;

0~999min timing range, the instrument stops automatically after the operation is over;

With 1~6 gears, the speed can be adjusted, which is suitable for different sample

processing requirements;

High-performance brushless motor, strong and efficient, stable operation, low noise, long life, can run for a long time;

Stepless speed regulation function, the max speed can reach 34000rpm, providing a linear speed of 27m/s for sample homogenization;

Two-way support rod design combined with double-hole fixing clips to form an integrated lifting adjustment system to make your experiments more reliable and safer;

The digital display model can be equipped with a temperature sensor to measure the temperature of the sample in real time. When it reaches the set value, it will automatically stop running, making the experiment safe and secure.

Technical Parameters

Model HR-25

Item No 1004023000

Type Basic

Rated Voltage (V) 200-240(optional 110V)

Frequency 50-60HZ

Rated Input Power 1500W

Rated Output Power 1250W

Max Input Power 2300w

Max Output Power 1700w

Motor type DC Brushless motor

Speed range 7500-30000rpm

Speed control gear

Capacity 0.2-10000ml

Set Standard Machine+working head+stand

Standard working head HR25 25g-S2V

Machine Size 410*90mm

Machine packing Size 470*340*205mm

Machine NW 2.6KG

Machine GW 3KG

Set NW 7KG

Set GW 8KG
